TECHNICAL SPECIFICATIONS

Capacity

250 pes / min max

Bag width

80-680 mm max (min-max)

Bag length

80-1000 mm (min-max)

Film thickness

0.020-0.100 mm (min-max)

Servo Motor

4 unit

Photocell

1 unit

Total electric power

11 kw (380 V-50HZ)

Total air supply

300lt/min-6 Bar min

MACHINE DIMENSIONS AND WEIGHT

Machine lenght

5420 mm

Machine width

1550 mm

Machine height

1820 mm

Machine weight

1800 kg

EQUIPMENT USED

Operator Panel

OMRON (Japan)

Servo Motor

OMRON (Japan)

AC Motor

ELK MOTOR (Turkey)

Reductor

YILMAZ REDUKTÖR (Turkey)

Pneumatic System

FESTO (Gernany)

Proximity Sensors and Photocells

SICK (Germany)

Contactors and Fuses

SCHNEIDER ELECTRIC (France)

Metal Series Buttons

TELEMECANIQUE, SCHNEIDER (France)

Bearing

SKF, FAG (Germany) ve ORS (Turkey)

STANDARD FEATURES

Through  the touch screen operator panel, the feature of displaying the bag length, number of bags, production speed, number of bags in the package, stopping in the total count.

 There is 1 photocell. Cuts printed and unprinted bag

 It cuts at high speed and with the desired measurement precision through the servo motor controlled pulling rollers

 Through to the servo motor controlled welding jaw, it provides strong and high quality welding.

 Through to the servo motor controlled belt system, belts run synchronously to the stacking system.

Through to the servo motor controlled stacking rollers, it is ensured to stack with quality,

 Warp rollers with inverter tension control system

 Pneumatic ballerina system

 Automatic edge control system

 Automatically stops when the roll runs out

 Photocell printing stops automatically when the location is not correct

 Roll bobbin binding diameter max 800 mm

 Ability to work in PP, OPP, CPP, High Density Polyethylene (HDPE), Low Density Polyethylene (LDPE), bags

     STANDARD EQUIPMENT

 PP SIDE SEALING ( PICKAXE ) JAW

 PE SIDE SEALING ( PICKAXE ) JAW

 BAND DEVICE
