تعديل تفاصيل منتج -
Electro-hydraulic safety barrier - opening...
معاينة
حفظ
حفظ ومتابعة التعديل
نسخ المنتج
حذف
الرقم التعريفى
تم الإنشاء فى
14/2/2024 10:50:09 ص
تم التحديث فى
19/2/2024 10:29:09 ص
الرابط الخاص بصفحة المنتج
https://www.alderishop.com/-6-425/
نوع المنتج
Simple product
Grouped product
Bundled product
تم النشر
الرؤية
Fully visible
In search results
On product detail pages
Not visible
قالب المنتج
Default Product Template
اساسي
English
العربية
Turkce
Russian (Russia)
السلوفاكية (سلوفاكيا)
إسم المنتج
وصف قصير
وصف كامل
<ul><li>It can be opened within 4-6 seconds to prevent traffic disruption.</li><li>It is designed as standard to manually open the road in the event of a power outage.</li><li>It is also designed to close the road within one second for emergency situations.</li><li><span data-sheets-root="1" data-sheets-value="{"1":2,"2":"Technical information:"}" data-sheets-userformat="{"2":513,"3":{"1":0},"12":0}" style="">Technical information:<br></span><br><google-sheets-html-origin style="color: rgb(0, 0, 0); font-size: medium;"><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; font-size: 10pt; font-family: Arial; width: 0px; border: none;"><colgroup><col width="230"><col width="89"><col width="97"><col width="96"><col width="110"><col width="88"><col width="100"></colgroup><tbody><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Type"}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"TANK PL SERIES"}" style="border-width: 1px; border-style: solid; border-color: rgb(0, 0, 0) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TANK PL SERIES</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Dimensions"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Dimensions</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"500x220x8mm"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">500x220x8mm</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Model"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Model</td><td data-sheets-value="{"1":2,"2":"TPL-1"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-1</td><td data-sheets-value="{"1":2,"2":"TPL-2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-2</td><td data-sheets-value="{"1":2,"2":"TPL-3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-3</td><td data-sheets-value="{"1":2,"2":"TPL-4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-4</td><td data-sheets-value="{"1":2,"2":"TPL-5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-5</td><td data-sheets-value="{"1":2,"2":"TPL-6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-6</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Rising bollard number of"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Rising bollard number of</td><td data-sheets-value="{"1":2,"2":"Unary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Unary</td><td data-sheets-value="{"1":2,"2":"Binary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Binary</td><td data-sheets-value="{"1":2,"2":"Triad"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Triad</td><td data-sheets-value="{"1":2,"2":"Quad"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Quad</td><td data-sheets-value="{"1":2,"2":"Quinary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Quinary</td><td data-sheets-value="{"1":2,"2":"Senary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Senary</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Moving part"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Moving part</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"On 6mm ST37 steel pipe, 2mm 316 quality, stainless"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">On 6mm ST37 steel pipe, 2mm 316 quality, stainless</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Working system"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Working system</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hydraulic"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hydraulic</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Power source"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Power source</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"380 V 3 Phase 50/60 Hz"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">380 V 3 Phase 50/60 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Control unit"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Control unit</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"T-mag control unit or (optional PLC)"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">T-mag control unit or (optional PLC)</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Current draw"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Current draw</td><td data-sheets-value="{"1":2,"2":"2,1 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">2,1 A</td><td data-sheets-value="{"1":2,"2":"3,5 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3,5 A</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"6,6 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">6,6 A</td><td data-sheets-value="{"1":2,"2":"8,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">8,2 A</td><td data-sheets-value="{"1":2,"2":"11,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">11,2 A</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Motor power"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Motor power</td><td data-sheets-value="{"1":2,"2":"0,75 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">0,75 KW</td><td data-sheets-value="{"1":2,"2":"1,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">1,5 KW</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"3 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3 KW</td><td data-sheets-value="{"1":2,"2":"4 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">4 KW</td><td data-sheets-value="{"1":2,"2":"5,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">5,5 KW</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Turn on-turn off duration"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Turn on-turn off duration</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"4-6 seconds"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">4-6 seconds</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Continuously of operation"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Continuously of operation</td><td rowspan="1" colspan="6" data-sheets-value="{"1":3,"3":1}" data-sheets-numberformat="{"1":3,"2":"0%","3":1}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">100%</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Lifting power per rising bollard"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Lifting power per rising bollard</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"750 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">750 Kg</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Limit switch type"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Limit switch type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Adjustable motor operational"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Adjustable motor operational</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Minimum operational pressure"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Minimum operational pressure</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"20 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">20 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Maximum operational pressure"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Maximum operational pressure</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"75 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">75 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel opening"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel opening</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Through ball valve"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Through ball valve</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel shut down"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel shut down</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Optional hand pump"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Optional hand pump</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hydraulic oil type"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hydraulic oil type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hydraulic oil No.32 or 46"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hydraulic oil No.32 or 46</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Rai colour for bollard"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Rai colour for bollard</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Polisage stainless steel"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">Polisage stainless steel</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Notification light"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Notification light</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Specially designed led system in top-hat"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Specially designed led system in top-hat</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hydraulic pipe"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hydraulic pipe</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"3/8 r2 330 bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3/8 r2 330 bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Operational temperature"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Operational temperature</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"-20°C min +70°C max"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">-20°C min +70°C max</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Bollard ground weight"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Bollard ground weight</td><td data-sheets-value="{"1":2,"2":"110 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg</td><td data-sheets-value="{"1":2,"2":"110 Kg x 2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 2</td><td data-sheets-value="{"1":2,"2":"110 Kg x 3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 3</td><td data-sheets-value="{"1":2,"2":"110 Kg x 4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 4</td><td data-sheets-value="{"1":2,"2":"110 Kg x 5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 5</td><td data-sheets-value="{"1":2,"2":"110 Kg x 6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 6</td></tr></tbody></table></google-sheets-html-origin></li></ul>
It can be opened within 4-6 seconds to prevent traffic disruption.
It is designed as standard to manually open the road in the event of a power outage.
It is also designed to close the road within one second for emergency situations.
Technical information:
Type
TANK PL SERIES
Dimensions
500x220x8mm
Model
TPL-1
TPL-2
TPL-3
TPL-4
TPL-5
TPL-6
Rising bollard number of
Unary
Binary
Triad
Quad
Quinary
Senary
Moving part
On 6mm ST37 steel pipe, 2mm 316 quality, stainless
Working system
Hydraulic
Power source
380 V 3 Phase 50/60 Hz
Control unit
T-mag control unit or (optional PLC)
Current draw
2,1 A
3,5 A
6,6 A
8,2 A
11,2 A
Motor power
0,75 KW
1,5 KW
3 KW
4 KW
5,5 KW
Turn on-turn off duration
4-6 seconds
Continuously of operation
100%
Lifting power per rising bollard
750 Kg
Limit switch type
Adjustable motor operational
Minimum operational pressure
20 Bar
Maximum operational pressure
75 Bar
Manuel opening
Through ball valve
Manuel shut down
Optional hand pump
Hydraulic oil type
Hydraulic oil No.32 or 46
Rai colour for bollard
Polisage stainless steel
Notification light
Specially designed led system in top-hat
Hydraulic pipe
3/8 r2 330 bar
Operational temperature
-20°C min +70°C max
Bollard ground weight
110 Kg
110 Kg x 2
110 Kg x 3
110 Kg x 4
110 Kg x 5
110 Kg x 6
إسم المنتج
وصف قصير
وصف كامل
<ul><li>It can be opened within 4-6 seconds to prevent traffic disruption.</li><li>It is designed as standard to manually open the road in the event of a power outage.</li><li>It is also designed to close the road within one second for emergency situations.</li><li>It can be opened within 4-6 seconds to prevent traffic disruption.</li><li>It is designed as standard to manually open the road in the event of a power outage.</li><li>It is also designed to close the road within one second for emergency situations.</li><li><span data-sheets-root="1" data-sheets-value="{"1":2,"2":"Technical information:"}" data-sheets-userformat="{"2":513,"3":{"1":0},"12":0}">Technical information:<br></span><br><google-sheets-html-origin style="color: rgb(0, 0, 0); font-size: medium;"><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; font-size: 10pt; font-family: Arial; width: 0px; border: none;"><colgroup><col width="230"><col width="89"><col width="97"><col width="96"><col width="110"><col width="88"><col width="100"></colgroup><tbody><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Type"}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"TANK PL SERIES"}" style="border-width: 1px; border-style: solid; border-color: rgb(0, 0, 0) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TANK PL SERIES</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Dimensions"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Dimensions</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"500x220x8mm"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">500x220x8mm</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Model"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Model</td><td data-sheets-value="{"1":2,"2":"TPL-1"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-1</td><td data-sheets-value="{"1":2,"2":"TPL-2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-2</td><td data-sheets-value="{"1":2,"2":"TPL-3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-3</td><td data-sheets-value="{"1":2,"2":"TPL-4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-4</td><td data-sheets-value="{"1":2,"2":"TPL-5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-5</td><td data-sheets-value="{"1":2,"2":"TPL-6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-6</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Rising bollard number of"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Rising bollard number of</td><td data-sheets-value="{"1":2,"2":"Unary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Unary</td><td data-sheets-value="{"1":2,"2":"Binary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Binary</td><td data-sheets-value="{"1":2,"2":"Triad"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Triad</td><td data-sheets-value="{"1":2,"2":"Quad"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Quad</td><td data-sheets-value="{"1":2,"2":"Quinary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Quinary</td><td data-sheets-value="{"1":2,"2":"Senary"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Senary</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Moving part"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Moving part</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"On 6mm ST37 steel pipe, 2mm 316 quality, stainless"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">On 6mm ST37 steel pipe, 2mm 316 quality, stainless</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Working system"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Working system</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hydraulic"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hydraulic</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Power source"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Power source</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"380 V 3 Phase 50/60 Hz"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">380 V 3 Phase 50/60 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Control unit"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Control unit</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"T-mag control unit or (optional PLC)"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">T-mag control unit or (optional PLC)</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Current draw"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Current draw</td><td data-sheets-value="{"1":2,"2":"2,1 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">2,1 A</td><td data-sheets-value="{"1":2,"2":"3,5 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3,5 A</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"6,6 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">6,6 A</td><td data-sheets-value="{"1":2,"2":"8,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">8,2 A</td><td data-sheets-value="{"1":2,"2":"11,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">11,2 A</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Motor power"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Motor power</td><td data-sheets-value="{"1":2,"2":"0,75 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">0,75 KW</td><td data-sheets-value="{"1":2,"2":"1,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">1,5 KW</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"3 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3 KW</td><td data-sheets-value="{"1":2,"2":"4 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">4 KW</td><td data-sheets-value="{"1":2,"2":"5,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">5,5 KW</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Turn on-turn off duration"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Turn on-turn off duration</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"4-6 seconds"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">4-6 seconds</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Continuously of operation"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Continuously of operation</td><td rowspan="1" colspan="6" data-sheets-value="{"1":3,"3":1}" data-sheets-numberformat="{"1":3,"2":"0%","3":1}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">100%</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Lifting power per rising bollard"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Lifting power per rising bollard</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"750 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">750 Kg</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Limit switch type"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Limit switch type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Adjustable motor operational"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Adjustable motor operational</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Minimum operational pressure"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Minimum operational pressure</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"20 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">20 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Maximum operational pressure"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Maximum operational pressure</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"75 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">75 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel opening"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel opening</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Through ball valve"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Through ball valve</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel shut down"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel shut down</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Optional hand pump"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Optional hand pump</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hydraulic oil type"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hydraulic oil type</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hydraulic oil No.32 or 46"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hydraulic oil No.32 or 46</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Rai colour for bollard"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Rai colour for bollard</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Polisage stainless steel"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">Polisage stainless steel</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Notification light"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Notification light</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Specially designed led system in top-hat"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Specially designed led system in top-hat</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hydraulic pipe"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hydraulic pipe</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"3/8 r2 330 bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3/8 r2 330 bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Operational temperature"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Operational temperature</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"-20°C min +70°C max"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">-20°C min +70°C max</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Bollard ground weight"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Bollard ground weight</td><td data-sheets-value="{"1":2,"2":"110 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg</td><td data-sheets-value="{"1":2,"2":"110 Kg x 2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 2</td><td data-sheets-value="{"1":2,"2":"110 Kg x 3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 3</td><td data-sheets-value="{"1":2,"2":"110 Kg x 4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 4</td><td data-sheets-value="{"1":2,"2":"110 Kg x 5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 5</td><td data-sheets-value="{"1":2,"2":"110 Kg x 6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 6</td></tr></tbody></table></google-sheets-html-origin></li><li><span data-sheets-root="1" data-sheets-value="{"1":2,"2":"Technical information:"}" data-sheets-userformat="{"2":513,"3":{"1":0},"12":0}">Technical information:<br><br><br></span></li></ul>
It can be opened within 4-6 seconds to prevent traffic disruption.
It is designed as standard to manually open the road in the event of a power outage.
It is also designed to close the road within one second for emergency situations.
It can be opened within 4-6 seconds to prevent traffic disruption.
It is designed as standard to manually open the road in the event of a power outage.
It is also designed to close the road within one second for emergency situations.
Technical information:
Type
TANK PL SERIES
Dimensions
500x220x8mm
Model
TPL-1
TPL-2
TPL-3
TPL-4
TPL-5
TPL-6
Rising bollard number of
Unary
Binary
Triad
Quad
Quinary
Senary
Moving part
On 6mm ST37 steel pipe, 2mm 316 quality, stainless
Working system
Hydraulic
Power source
380 V 3 Phase 50/60 Hz
Control unit
T-mag control unit or (optional PLC)
Current draw
2,1 A
3,5 A
6,6 A
8,2 A
11,2 A
Motor power
0,75 KW
1,5 KW
3 KW
4 KW
5,5 KW
Turn on-turn off duration
4-6 seconds
Continuously of operation
100%
Lifting power per rising bollard
750 Kg
Limit switch type
Adjustable motor operational
Minimum operational pressure
20 Bar
Maximum operational pressure
75 Bar
Manuel opening
Through ball valve
Manuel shut down
Optional hand pump
Hydraulic oil type
Hydraulic oil No.32 or 46
Rai colour for bollard
Polisage stainless steel
Notification light
Specially designed led system in top-hat
Hydraulic pipe
3/8 r2 330 bar
Operational temperature
-20°C min +70°C max
Bollard ground weight
110 Kg
110 Kg x 2
110 Kg x 3
110 Kg x 4
110 Kg x 5
110 Kg x 6
Technical information:
إسم المنتج
وصف قصير
وصف كامل
<ul><li>يمكن فتحها خلال 4-6 ثوانٍ لمنع انقطاع حركة المرور.</li><li>تم تصميمه بشكل قياسي لفتح الطريق يدويًا في حالة انقطاع التيار الكهربائي.</li><li>كما أنه مصمم لإغلاق الطريق خلال ثانية واحدة لحالات الطوارئ.</li><li>المعلومات التقنية:<br><br><google-sheets-html-origin style="color: rgb(0, 0, 0); font-size: medium;"><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; font-size: 10pt; font-family: Arial; width: 0px; border: none;"><colgroup><col width="88"><col width="89"><col width="97"><col width="96"><col width="110"><col width="88"><col width="226"></colgroup><tbody><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"TANK PL SERIES"}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TANK PL SERIES</td><td data-sheets-value="{"1":2,"2":"النوع "}" style="border-width: 1px; border-style: solid; border-color: rgb(0, 0, 0) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">النوع</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"500 × 220 × 8 ملم"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">500 × 220 × 8 ملم</td><td data-sheets-value="{"1":2,"2":"أبعاد"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">أبعاد</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"TPL-1"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-1</td><td data-sheets-value="{"1":2,"2":"TPL-2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-2</td><td data-sheets-value="{"1":2,"2":"TPL-3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-3</td><td data-sheets-value="{"1":2,"2":"TPL-4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-4</td><td data-sheets-value="{"1":2,"2":"TPL-5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-5</td><td data-sheets-value="{"1":2,"2":"TPL-6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-6</td><td data-sheets-value="{"1":2,"2":"النماذج"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">النماذج</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"أحادي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">أحادي</td><td data-sheets-value="{"1":2,"2":"ثنائي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">ثنائي</td><td data-sheets-value="{"1":2,"2":"ثلاثي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">ثلاثي</td><td data-sheets-value="{"1":2,"2":"رباعي "}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">رباعي</td><td data-sheets-value="{"1":2,"2":" خماسي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">خماسي</td><td data-sheets-value="{"1":2,"2":"سداسي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">سداسي</td><td data-sheets-value="{"1":2,"2":"ارتفاع عدد الأعمدة"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">ارتفاع عدد الأعمدة</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":" ST37 مقاس 6 مم، جودة 2 مم 316، مقاومة للصدأ"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">ST37 مقاس 6 مم، جودة 2 مم 316، مقاومة للصدأ</td><td data-sheets-value="{"1":2,"2":"جزء متحرك"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">جزء متحرك</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"هيدروليكي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">هيدروليكي</td><td data-sheets-value="{"1":2,"2":"نظام العمل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">نظام العمل</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"380 فولت 3 فاز 50/60 هرتز"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">380 فولت 3 مراحل 50/60 هرتز</td><td data-sheets-value="{"1":2,"2":"مصدر الطاقة"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">مصدر الطاقة</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"وحدة التحكم T-mag أو (PLC اختياري)"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">وحدة التحكم T-mag أو (PLC اختياري)</td><td data-sheets-value="{"1":2,"2":"وحدة التحكم"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">وحدة التحكم</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"2,1 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">2,1 A</td><td data-sheets-value="{"1":2,"2":"3,5 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3,5 A</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"6,6 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">6,6 A</td><td data-sheets-value="{"1":2,"2":"8,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">8,2 A</td><td data-sheets-value="{"1":2,"2":"11,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">11,2 A</td><td data-sheets-value="{"1":2,"2":"السحب الحالي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">السحب الحالي</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"0,75 كيلو واط"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">0,75 كيلو واط</td><td data-sheets-value="{"1":2,"2":"1,5 كيلو واط"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">1,5 كيلو واط</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"3 كيلو واط"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3 كيلو واط</td><td data-sheets-value="{"1":2,"2":"4 كيلو واط"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">4 كيلو واط</td><td data-sheets-value="{"1":2,"2":"5,5 كيلو واط"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">5,5 كيلو واط</td><td data-sheets-value="{"1":2,"2":"قوة المحرك"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">قوة المحرك</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"4-6 ثانية"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">4-6 ثانية</td><td data-sheets-value="{"1":2,"2":"تشغيل وإيقاف المدة"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">تشغيل وإيقاف المدة</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":3,"3":1}" data-sheets-numberformat="{"1":3,"2":"0%","3":1}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">100%</td><td data-sheets-value="{"1":2,"2":"استمرارية التشغيل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">استمرارية التشغيل</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"750 كجم"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">750 كجم</td><td data-sheets-value="{"1":2,"2":"قوة الرفع لكل حاجز مرتفع"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">قوة الرفع لكل حاجز مرتفع</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"محرك قابل للتعديل في حالة عمل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">محرك قابل للتعديل في حالة عمل</td><td data-sheets-value="{"1":2,"2":"الحد من نوع التبديل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">الحد من نوع التبديل</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"20 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">20 Bar</td><td data-sheets-value="{"1":2,"2":"الحد الأدنى من الضغط التشغيلي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">الحد الأدنى من الضغط التشغيلي</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"75 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">75 Bar</td><td data-sheets-value="{"1":2,"2":"أقصى ضغط تشغيلي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">أقصى ضغط تشغيلي</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"من خلال صمام الكرة"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">من خلال صمام الكرة</td><td data-sheets-value="{"1":2,"2":"افتتاح مانويل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">افتتاح مانويل</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"مضخة يدوية اختيارية"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">مضخة يدوية اختيارية</td><td data-sheets-value="{"1":2,"2":"مانويل اغلق"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">مانويل اغلق</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"زيت هيدروليك رقم 32 أو 46"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">زيت هيدروليك رقم 32 أو 46</td><td data-sheets-value="{"1":2,"2":"نوع الزيت الهيدروليكي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">نوع الزيت الهيدروليكي</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"تلميع الفولاذ المقاوم للصدأ"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">تلميع الفولاذ المقاوم للصدأ</td><td data-sheets-value="{"1":2,"2":"لون لحاجز"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">لون لحاجز</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"نظام LED مصمم خصيصًا في القبعة العلوية"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">نظام LED مصمم خصيصًا في القبعة العلوية</td><td data-sheets-value="{"1":2,"2":"ضوء الإخطار"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">ضوء الإخطار</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"3/8 r2 330 bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3/8 r2 330 bar</td><td data-sheets-value="{"1":2,"2":"الأنابيب الهيدروليكية"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">الأنابيب الهيدروليكية</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"-20 درجة مئوية دقيقة +70 درجة مئوية كحد أقصى"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">-20 درجة مئوية دقيقة +70 درجة مئوية كحد أقصى</td><td data-sheets-value="{"1":2,"2":"درجة حرارة التشغيل"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">درجة حرارة التشغيل</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"110 كجم"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم</td><td data-sheets-value="{"1":2,"2":"110 كجم × 2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم × 2</td><td data-sheets-value="{"1":2,"2":"110 كجم × 3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم × 3</td><td data-sheets-value="{"1":2,"2":"110 كجم × 4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم × 4</td><td data-sheets-value="{"1":2,"2":"110 كجم × 5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم × 5</td><td data-sheets-value="{"1":2,"2":"110 كجم × 6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 كجم × 6</td><td data-sheets-value="{"1":2,"2":" الوزن الأرضي"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">الوزن الأرضي</td></tr></tbody></table></google-sheets-html-origin><br><br></li></ul>
يمكن فتحها خلال 4-6 ثوانٍ لمنع انقطاع حركة المرور.
تم تصميمه بشكل قياسي لفتح الطريق يدويًا في حالة انقطاع التيار الكهربائي.
كما أنه مصمم لإغلاق الطريق خلال ثانية واحدة لحالات الطوارئ.
المعلومات التقنية:
TANK PL SERIES
النوع
500 × 220 × 8 ملم
أبعاد
TPL-1
TPL-2
TPL-3
TPL-4
TPL-5
TPL-6
النماذج
أحادي
ثنائي
ثلاثي
رباعي
خماسي
سداسي
ارتفاع عدد الأعمدة
ST37 مقاس 6 مم، جودة 2 مم 316، مقاومة للصدأ
جزء متحرك
هيدروليكي
نظام العمل
380 فولت 3 مراحل 50/60 هرتز
مصدر الطاقة
وحدة التحكم T-mag أو (PLC اختياري)
وحدة التحكم
2,1 A
3,5 A
6,6 A
8,2 A
11,2 A
السحب الحالي
0,75 كيلو واط
1,5 كيلو واط
3 كيلو واط
4 كيلو واط
5,5 كيلو واط
قوة المحرك
4-6 ثانية
تشغيل وإيقاف المدة
100%
استمرارية التشغيل
750 كجم
قوة الرفع لكل حاجز مرتفع
محرك قابل للتعديل في حالة عمل
الحد من نوع التبديل
20 Bar
الحد الأدنى من الضغط التشغيلي
75 Bar
أقصى ضغط تشغيلي
من خلال صمام الكرة
افتتاح مانويل
مضخة يدوية اختيارية
مانويل اغلق
زيت هيدروليك رقم 32 أو 46
نوع الزيت الهيدروليكي
تلميع الفولاذ المقاوم للصدأ
لون لحاجز
نظام LED مصمم خصيصًا في القبعة العلوية
ضوء الإخطار
3/8 r2 330 bar
الأنابيب الهيدروليكية
-20 درجة مئوية دقيقة +70 درجة مئوية كحد أقصى
درجة حرارة التشغيل
110 كجم
110 كجم × 2
110 كجم × 3
110 كجم × 4
110 كجم × 5
110 كجم × 6
الوزن الأرضي
إسم المنتج
وصف قصير
وصف كامل
<ul><li>Tank PL Serisi Mantar Bariyerler trafiğin aksamaması için 4-6 saniye arasında açılabilecek</li><li>elektrik kesintilerinde yolu manuel olarak açabilecek şekilde standart olarak tasarlanmıştır.</li><li>acil durumlar için 1 saniyede yolu kapatacak şekilde de üretilmektedir.</li><li><span data-sheets-root="1" data-sheets-value="{"1":2,"2":"Teknik Özellikler"}" data-sheets-userformat="{"2":513,"3":{"1":0},"12":0}" style="">Teknik Özellikler:<br><br><google-sheets-html-origin style="color: rgb(0, 0, 0); font-size: medium;"><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; font-size: 10pt; font-family: Arial; width: 0px; border: none;"><colgroup><col width="230"><col width="89"><col width="97"><col width="96"><col width="110"><col width="88"><col width="100"></colgroup><tbody><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Tip"}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Tip</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"TANK PL SERIES"}" style="border-width: 1px; border-style: solid; border-color: rgb(0, 0, 0) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TANK PL SERIES</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Boyutlar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Boyutlar</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"500x220x8mm"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">500x220x8mm</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Modeli"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Modeli</td><td data-sheets-value="{"1":2,"2":"TPL-1"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-1</td><td data-sheets-value="{"1":2,"2":"TPL-2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-2</td><td data-sheets-value="{"1":2,"2":"TPL-3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-3</td><td data-sheets-value="{"1":2,"2":"TPL-4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-4</td><td data-sheets-value="{"1":2,"2":"TPL-5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-5</td><td data-sheets-value="{"1":2,"2":"TPL-6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; font-weight: bold; text-align: center;">TPL-6</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Yükselen baba sayısı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Yükselen baba sayısı</td><td data-sheets-value="{"1":2,"2":"Tekli "}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Tekli</td><td data-sheets-value="{"1":2,"2":"İkili "}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">İkili</td><td data-sheets-value="{"1":2,"2":"Üçlü "}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Üçlü</td><td data-sheets-value="{"1":2,"2":"Dörtlü"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Dörtlü</td><td data-sheets-value="{"1":2,"2":" Beşli "}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Beşli</td><td data-sheets-value="{"1":2,"2":"Altılı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Altılı</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hareketli parça"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hareketli parça</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"6mm ST37 çelik boru üzerine, 2mm 316 kalite, paslanmaz"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">6mm ST37 çelik boru üzerine, 2mm 316 kalite, paslanmaz</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Çalışma sistemi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Çalışma sistemi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hidrolik"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hidrolik</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Güç kaynağı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Güç kaynağı</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"380 V 3 Faz 50/60 Hz"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">380 V 3 Faz 50/60 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Kontrol ünitesi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Kontrol ünitesi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"T-mag kontrol ünitesi veya (isteğe bağlı PLC)"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">T-mag kontrol ünitesi veya (isteğe bağlı PLC)</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Mevcut çizim"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Mevcut çizim</td><td data-sheets-value="{"1":2,"2":"2,1 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">2,1 A</td><td data-sheets-value="{"1":2,"2":"3,5 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3,5 A</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"6,6 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">6,6 A</td><td data-sheets-value="{"1":2,"2":"8,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">8,2 A</td><td data-sheets-value="{"1":2,"2":"11,2 A"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">11,2 A</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Motor gücü"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Motor gücü</td><td data-sheets-value="{"1":2,"2":"0,75 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">0,75 KW</td><td data-sheets-value="{"1":2,"2":"1,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">1,5 KW</td><td rowspan="1" colspan="2" data-sheets-value="{"1":2,"2":"3 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3 KW</td><td data-sheets-value="{"1":2,"2":"4 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">4 KW</td><td data-sheets-value="{"1":2,"2":"5,5 KW"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">5,5 KW</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Açma-kapama süresi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Açma-kapama süresi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"4-6 saniye"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: top; text-align: center;">4-6 saniye</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Sürekli çalışma"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Sürekli çalışma</td><td rowspan="1" colspan="6" data-sheets-value="{"1":3,"3":1}" data-sheets-numberformat="{"1":3,"2":"0%","3":1}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">100%</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Yükselen baba başına kaldırma gücü"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Yükselen baba başına kaldırma gücü</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"750 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">750 Kg</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Limit anahtarı tipi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Limit anahtarı tipi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Ayarlanabilir motor çalışır durumda"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Ayarlanabilir motor çalışır durumda</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Minimum çalışma basıncı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Minimum çalışma basıncı</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"20 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">20 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Maksimum çalışma basıncı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Maksimum çalışma basıncı</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"75 Bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">75 Bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel açma"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel açma</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Küresel vana aracılığıyla"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Küresel vana aracılığıyla</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Manuel kapatma"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Manuel kapatma</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Opsiyonel el pompası"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Opsiyonel el pompası</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hidrolik yağ tipi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hidrolik yağ tipi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Hidrolik yağı No.32 veya 46"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Hidrolik yağı No.32 veya 46</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Baba için Rai rengi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Baba için Rai rengi</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Polisage paslanmaz çelik"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Polisage paslanmaz çelik</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Bilgilendirme ışığı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Bilgilendirme ışığı</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"Silindir şapkada özel tasarlanmış led sistemi"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">Silindir şapkada özel tasarlanmış led sistemi</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Hidrolik boru"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Hidrolik boru</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"3/8 r2 330 bar"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">3/8 r2 330 bar</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Çalışma sıcaklığı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Çalışma sıcaklığı</td><td rowspan="1" colspan="6" data-sheets-value="{"1":2,"2":"-20°C min +70°C max"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">-20°C min +70°C max</td></tr><tr style="height: 21px;"><td data-sheets-value="{"1":2,"2":"Baba zemin ağırlığı"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom;">Baba zemin ağırlığı</td><td data-sheets-value="{"1":2,"2":"110 Kg"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg</td><td data-sheets-value="{"1":2,"2":"110 Kg x 2"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 2</td><td data-sheets-value="{"1":2,"2":"110 Kg x 3"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 3</td><td data-sheets-value="{"1":2,"2":"110 Kg x 4"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 4</td><td data-sheets-value="{"1":2,"2":"110 Kg x 5"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 5</td><td data-sheets-value="{"1":2,"2":"110 Kg x 6"}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; text-align: center;">110 Kg x 6</td></tr></tbody></table></google-sheets-html-origin></span><br><br></li></ul>
Tank PL Serisi Mantar Bariyerler trafiğin aksamaması için 4-6 saniye arasında açılabilecek
elektrik kesintilerinde yolu manuel olarak açabilecek şekilde standart olarak tasarlanmıştır.
acil durumlar için 1 saniyede yolu kapatacak şekilde de üretilmektedir.
Teknik Özellikler:
Tip
TANK PL SERIES
Boyutlar
500x220x8mm
Modeli
TPL-1
TPL-2
TPL-3
TPL-4
TPL-5
TPL-6
Yükselen baba sayısı
Tekli
İkili
Üçlü
Dörtlü
Beşli
Altılı
Hareketli parça
6mm ST37 çelik boru üzerine, 2mm 316 kalite, paslanmaz
Çalışma sistemi
Hidrolik
Güç kaynağı
380 V 3 Faz 50/60 Hz
Kontrol ünitesi
T-mag kontrol ünitesi veya (isteğe bağlı PLC)
Mevcut çizim
2,1 A
3,5 A
6,6 A
8,2 A
11,2 A
Motor gücü
0,75 KW
1,5 KW
3 KW
4 KW
5,5 KW
Açma-kapama süresi
4-6 saniye
Sürekli çalışma
100%
Yükselen baba başına kaldırma gücü
750 Kg
Limit anahtarı tipi
Ayarlanabilir motor çalışır durumda
Minimum çalışma basıncı
20 Bar
Maksimum çalışma basıncı
75 Bar
Manuel açma
Küresel vana aracılığıyla
Manuel kapatma
Opsiyonel el pompası
Hidrolik yağ tipi
Hidrolik yağı No.32 veya 46
Baba için Rai rengi
Polisage paslanmaz çelik
Bilgilendirme ışığı
Silindir şapkada özel tasarlanmış led sistemi
Hidrolik boru
3/8 r2 330 bar
Çalışma sıcaklığı
-20°C min +70°C max
Baba zemin ağırlığı
110 Kg
110 Kg x 2
110 Kg x 3
110 Kg x 4
110 Kg x 5
110 Kg x 6
