It is a high safety barrier control system developed for parking lots.
It allows vehicles to enter and leave the parking lot quickly and safely, thanks to tags or cards attached to the vehicles.
If a vehicle approaching the barrier is allowed, the barrier is opened without stopping the vehicle, allowing comfortable and safe passage.

Technical data:

Important Specifications
Support Protocol	IS018000-6C EPC Gen2 / IS018000-6B
Operating Frequency	ISM 902MHz - 928MHz. Or 920MHz - 925MHz
Customization	860MHz - 960MHz
Working mode	Operating Mode FHSS or maed frequency hopping spread spectrum mode of operation defined by software
Transmit Power	20dBm - 30 dBm (defined by software)
Reading Writing performance
Reading Speed	For a single card, reading time is less than 10ms for 64-bit.
Reading Distance	4m - 8m (depends on the tag and the environment)
Writing Speed	Less than 30ms for 8-bit
Writing Distance	2m - 4m (depends on the tag and the environment)
Read Message	Alarm bell
Data Point Interface
RS232 Port	Available
RS485 Port	Available
Scaler Port	Weigand26/34
Trigger Port	Available
TCP/IP Port (RJ45)	Available
Elektrical Parameters
Power Supply	DC+9V.4A
Power Consumption	6W
Outer Dimension and Weight
Dimensions	235mmx235mmx50mm
Weight	1500g
Operating Ambient
Operating Temperature	20°C~70°C
