CCTV cables are used to connect video, audio and communication systems with each other as well as closed circuit TV systems.They are preferable for their flame retarding and halogen free charecteristics, which make them ideal for use in buildings with high population densities. CCTV cables are manufactured for various different uses.
Cable structure | |
Coaxial | Mini Coax |
Conductor | 0,34 mm² |
Insulation | SOLID PE |
Screen | Thin copper wire braid |
Cores for Control | HFFR 0,50 mm² / Ø 1,20 mm |
Control Core Colors | Red , Black |
General Screen | AL-PES TAPE |
Sheath | HFFR RAL 7001 GREY |
External Diameter | 6,10 mm |
Cable Weight | 52 Kg / Km |
Standard Length | 100 / 500 / 1000 m |
Code No | 102 12142 1061 |
Technicial Specifications | |
Conductor Resistance | 0.22 mm² = 79 Ω / km |
0.50 mm² = 39 Ω / km | |
Effective Capacity | 58 pF/m |
Impedance | 75 ± 3Ω |
Operating voltage | 250V |
Operating temperature | Fixed Fixed Laying -5 ° C ~ + 70 ° C |
Movable Flexible -30 ° C ~ + 80 ° C | |
min. Bending Radius | Fixed Fixed Laying 7,5 x D |
Movable Flexible 10 x D | |
Flame Test | IEC 60332-1 , EN 50265-2-1 |
