Hydraulic road barrier - takes up little ground space

Be the first to review this item Items In Box Not Applicable

Order your products and your quote will be sent within 24 hours

Container

Wholesale only Alternate Text

Share this product on social media

Proof Series Road Blocker is remembered with its being extra easy to use and has a very firm, durable build.
At where digging the ground is not much of a possibility, thanks to its accordion like structure, it takes less space and requires less digging work.

Technical information:

Type	PROOF SERIES
Model	WPF200	WPF300	WPF400
Length	2 mt	3 mt	4 mt
Movable Part	S235JR quality steel sheet - Upper sheet 10mm / Front - Side sheets 3-4mm
Working System	Hydraulic
Power Supply	380 V 3 Phases 50/60 Hz
Control Card	T-MAG Control Card
Current	3.8 A	5.15 A
Motor Power	1.5 KW	2.2 KW
Number of piston	Single Piston	Double Pistons
Opening Time	4-6 sec
Duty Cycle	100%
Lift power	900 Kg	1800 Kg
Limit Switch Type	Adjustable engine working period
Working Pressure Min	20 Bar
Working Pressure Max	75 Bar
Manual Opening	Global valve
Manual Closing	Optional Hand Pump
Hydraulic Oil Type	32 or 46 number hydraulic oil
Hydraulic Hose	3/8 R2 330 Bar
Working Temperature	-20°C min +70°C max
Accumulator Supply	None
Emergency Close	Optional
