The use of coated metal materials, polyurethane and plastic complementary materials in the product.
Height 1160 mm Depth 1000 mm (excluding footrest, rear wheels turned outward (rear)) Width 643 mm (from upper surface of armrest, outer space between armrests) Seat depth 440 mm Seating surface width 500 mm Backrest width 490 mm;
Soft polyurethane armrests. Its dimensions are 355 mm x 425 mm x 65 mm (highest, longest and widest heights. It is curved.)
fixing sheets and strips of sheet metal; 3mm, 4mm, 5mm, 6mm thickness DKP coated sheets
profile tube used in various parts of the structural system; Ø51x1.5 mm, Ø42x1.5 mm, Ø25x1.5 mm, Ø21x1.5 mm
Functional functions: armrests that can be opened and closed gradually
Footrest made of compact material that conforms to the patient's movements
A center composed of a plastic and metal material that seals the rear brake pedal of the two rear wheels
The seat part is made of PU material which can feel soft
Backrest section that can be reclined at any time made of soft polyurethane
Foot support platform gains position with back movement PU material gives smoothness, mechanical feature;
Foot support platform with backrest tilt and position with structure for movement;
The structural system consists of a diameter of 51 x 1.5mm, 42 x 1.5mm, 25 x 1.5mm, 21 x 1.5mm, 20 x 20 x 2 square tube and 3mm, 4mm, 5mm, 6mm plated DKP type sheet metal; type and property of DKP sheet metal coating; Coating thickness: 40 μm.
Wheel diameter used Rear wheels: 125 mm diameter TENTE, ROLKO, STEINCO, BLICKLE, or RHOMBUS center brand of enclosed wheels.
Front wheel: 300mm diameter TENTE, ROLCO, STEINCO, BLICKLE or RHOMBUS wheels. slab (type g/m2 weight);
The polyurethane body feels soft. Wheel diameter Rear wheels: 125 mm in diameter, front wheels: 300 mm Anti-static properties of the wheels No density of foam used
